Application of Single-Plate Screen Changers in Plastic Extrusion Molding

The application of single-plate extrusion screen changers in plastic extrusion molding is crucial, as their primary role is to filter out foreign particles and impurities in the plasticized polymer melt, thereby enhancing the quality of the extruded products. Below is a detailed analysis of the application of single-plate screen changers in plastic extrusion molding:

I. Application Fields

Single-plate screen changers are suitable for the extrusion molding process of various thermoplastic plastics, including but not limited to sheets, plates, tubes, profiles, blown films, cables, and granulation. In plastic extruders, single-plate screen changers ensure the purity and stability of the melt during the extrusion process through their unique structure and functionality.

II. Working Principle

Single-plate screen changers typically have two filtration stations, one in operation and one as a standby. When it is necessary to change the filter screen, the hydraulic device is activated to switch the stations in a very short period of time (usually less than 2 seconds), pushing out the dirty station and bringing in the standby station, thus completing the screen change process. This design ensures production continuity and stability.

III. Main Characteristics

Rapid Screen Change: Single-plate screen changers enable rapid screen changes, reducing production downtime and increasing production efficiency.

No Material Leakage: Utilizing pressure-driven sealing technology, the sealing gap can be automatically compensated to ensure no material leakage during the screen change process, minimizing raw material waste.

Simple Structure: Single-plate screen changers have a simple structure and are easy to connect, making them compatible with extruders of different specifications.

High Temperature and Pressure Resistance: Single-plate screen changers maintain good working performance under conditions of up to 50 MPa in pressure and 300°C in temperature.

IV. Application Advantages

Improved Product Quality: By filtering out impurities in the melt, single-plate screen changers significantly enhance the quality of the extruded products, making them more uniform and stable.

Extended Mold Life: Reducing impurity wear on molds helps extend their service life.

Energy Saving and Consumption Reduction: With the installation of single-plate screen changers, the continuity and stability of the production process are improved, thereby reducing energy consumption and labor intensity, achieving the goals of energy saving and consumption reduction.

V. Application Examples

Single-plate screen changers are widely used in various extrusion lines during plastic extrusion molding. For example, in blown film production lines, they ensure that the blown films have a uniform thickness and a smooth surface; in tube production lines, they prevent flaws or damage to the tube surface; and in granulation production lines, they ensure that the produced granules have uniform quality and stable performance.

In summary, single-plate screen changers have broad application prospects and significant advantages in plastic extrusion molding. Through their unique structure and functionality, single-plate screen changers ensure the continuity and stability of the extrusion molding process, improving product quality and production efficiency.
